Garment Shops Transfer Trolley Loading 20tons To Move Coil Approx 4

1 Set

MOQ

$4,800.00(1 - 2 Sets) $4,500.00(>=3 Sets)

τιμή

Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα

Χαρακτηριστικά

Προδιαγραφές

Condition: New

Applicable Industries: Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Printing Shops, Construction worksÂ , Energy & Mining, Food & Beverage Shops

Weight (KG): 20000

Showroom Location: None

Video outgoing-inspection: Provided

Machinery Test Report: Provided

Marketing Type: Ordinary Product

Warranty of core components: 2 years

Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Warranty: 2 years

After Warranty Service: Online support

Local Service Location: None

After-sales Service Provided: Field maintenance and repair service

Capacity: 1-100ton

Size: Customized Size

Power supply: Cable Power

Running speed: 0-35 M/min(Adjustable)

Πιστοποίηση: CE ISO SGS

Βασικές πληροφορίες

Πιστοποίηση: CE ISO SGS

Πληρωμής & Αποστολής Όροι

Packaging Details: The 100 Ton Steel Product Rail Mounted Self-Driven Trolley is packed with tarp and wooden case, We can also make package according to your requests.

Περιγραφή προϊόντων

100 Ton Steel Product Rail Mounted Self-Driven Trolley

Parameter

Model		BWP-2T	BWP-10T	BWP-20T	BWP-30T	BWP-50T	BWP-63T	BWP-150T
Rated load (T)		2	10	20	30	50	63	150
Table size	length(L)	2000	3600	4000	4500	5500	5600	10000
	Width(W)	1500	2000	2200	2200	2500	2500	3000
	Height(H)	450	500	550	600	650	700	1200
Wheel Base (mm)		1200	2600	2800	3200	4200	4300	7000
Wheel Diameter(mm)		Φ270	Φ300	Φ350	Φ400	Φ500	Φ600	Φ600
Ground Clearance (mm)		50	50	50	50	50	75	75
Motor Power (Kw)		1	1.6	2.2	3.5	5	6.3	15
Battery Capacity(Ah)		180	160	180	250	330	400	600
Battery Voltage(V)		24	48	48	48	48	48	72
Running Time When Full Load		4.32	4.8	4	3.5	3.3	3	2.9
Running Distance for one Charge(Km)		6.5	7.2	4.8	4.2	4	3.6	3.2
Max Wheel Load (KN)		14.4	42.6	77.7	110.4	174	221.4	265.2

Our Advantages:

Load capacity,table size and rail gauge can be customized on request.
Power supply mode: Battery powered,cable powered,low voltage rail powered,busbar powered.
Options: Warning light,radar detector,remote controller, electrical parts.
Run on rail or floor.
2 years warranty.
After-sale service provided ,engineer available overseas.

FAQ

1. Q: How to operate the transfer cart?

A: It’s equipped with a remote controller that is used by the operator to control the transfer car movement .

2. Q: How do you guarantee the quality of the products?

A: The cart will be tested before delivery,also we got the CE SGS SASO certificates.Don’t worry,We supply after-sale service worldwide.

3. Q: What is the leading time, delivery term, and payment term?
A: Usually our leading time is 45 days.About the delivery term, we accept , FOB, CIF. About the payment, we accept T/T or L/C, etc.
4. Q: Can we choose the power supply for industry transport car ?
A: Yes,such as the cable drum, battery powered ,low voltage powered, busbar powered ,trailing cable powered, etc.
